7050 Aluminium Ntawv
Kev pabcuam neeg siv khoom yog online. Nkag mus rau kev sib tham kom tau txais cov lus tshaj tawm tshiab.
Khoom muag
Customize
Hoobkas ncaj muag
7 hnub shipping
| 7050 Aluminium Ntawv |
7050 Aluminium Sheet yog lub zog muaj zog alloy. Nws tuaj yeem kho cua sov. Nws yog raws li 7075 txhuas phaj los ntawm kev nce cov ntsiab lus ntawm Zn thiab Cu. Txhawm rau kom muaj zog thiab hloov Cr nrog Zr kom txo tau qhov quenching rhiab heev
Lub ntsiab alloying ntawm 7050 txhuas phaj yog zinc. Magnesium ntxiv rau cov hlau uas muaj 3 feem pua -75 feem pua zinc. MgZn2 nrog lub zog tseem ceeb tuaj yeem tsim. Qhov kev kho cua sov ntawm cov hlau no zoo dua li ntawm MgZn2 alloy.
Feem ntau yog siv rau molding, mechanical khoom, tooling thiab fixtures. Tshwj xeeb tshaj yog siv rau cov qauv kev ntxhov siab uas xav tau lub zog siab thiab muaj zog corrosion kuj.
Tshuaj muaj pes tsawg leeg
| Si | Cu | Mg | Zn | Mn | Ti | Fe | Cr | Zr |
| Tsawg dua lossis sib npaug rau 0.12 | 2.0-2.6 | 1.9-2.6 | 5.7-6.7 | Tsawg dua lossis sib npaug rau 0.10 | Tsawg dua lossis sib npaug rau 0.06 | 0.00-0.15 | Tsawg dua lossis sib npaug rau 0.04 | 0.08-0.15 |
7050 Aluminium NtawvYam ntxwv
1. Lub corrosion kuj thiab toughness ntawm 7050 txhuas daim hlau yog siab tshaj 7075 txhuas daim hlau.
2. Lub quenching rhiab heev yog qhov tsawg. Qhov no tuaj yeem tuav nws cov khoom muaj zog. Kev nyuaj siab corrosion cracking kuj thiab tawg toughness qib.
3. 7050 txhuas phaj kuj muaj cov tshuaj tiv thaiv anodic oxidation zoo.
7050 Aluminium NtawvMechanical Properties
| Tensile zog (ksi) | 74 |
| Yield zog (ksi) | 64 |
| Elongation hauv 2 ″ feem pua | 10 |
| Thickness | ＜2.0 |
7050 Aluminium NtawvTechnical Parameters
| Hom alloy | 7050 aluminium phaj |
| Material State | F,O,T6,T651,T7451,H112 |
| Tmob plab | 1mm -600 hli |
| Wib idth | ± 1500mm |
| Ntev | 8000 hli |
| Tej daim ntawv thov | Golf pob taub hau, pwm, fixtures. |
Kev ua lag luam
Feem ntau siv rau nruab nrab thiab hnyav phaj extrusion, dawb forgings thiab tuag forgings. Pwm ua, khoom siv kho tshuab, cuab yeej thiab khoom siv. High-strength qauv nrog siab zog thiab muaj zog corrosion kuj.
Cim npe nrov: 7050 txhuas ntawv, Tuam Tshoj 7050 txhuas ntawv manufacturers
