1/8 Aluminium Alloy Sheet



1/8 txhuas ntawv yog hais txog ib daim ntawv txhuas nrog lub thickness ntawm 1/8 nti, uas tuaj yeem qhia tau tias yog 1/8″ lossis 0.125″;

Ntau npaum li cas yog 1/8 aluminium ntawv hloov mus rau mm?
1 nti=25.4 hli
1/8 nti=3.175 hli

1/8 "Aluminium Sheet Alloy Model

1/8 ″ txhuas ntawv tsuas yog sawv cev rau cov ntawv txhuas nrog lub thickness ntawm 1/8 nti. Rau cov qauv alloy, cov khoom siv yog 1050 1060 1100 3003 3004 3104 3105 5005 5052 5083 6061, thiab lwm yam;
Cov qauv sib txawv thiab 1/8 txhuas ntawv nrog cov sib txawv annealing xeev muaj cov khoom sib txawv, thov xaj raws li koj xav tau; 1/8 "5083 aluminium ntawvfeem ntau yog siv nyob rau hauv kev tsim cov tso tsheb hlau luam thiab nkoj vim nws muaj zog hardness thiab corrosion

tsis kam;

3004 1/8 txhuas checker phaj Vim nws muaj zog hardness thiab zoo machinability tshaj 1000 series, nws yog feem ntau siv nyob rau hauv lub pedals ntawm tsheb thiab zus tau tej cov hlau ntaiv;



Qhov ntau thiab tsawg ntawm 1/8 Aluminium Sheet

1/8 aluminium ntawv Qhov ntau thiab tsawg yog 4 × 8 ko taw, 5 × 10 ko taw, 4 × 10 ko taw, 1000 x 2000 mm, 1000 x 1500 mm, 1500 x 3000 mm, 1500 x 2000mm, thiab lwm yam. Peb txais 1/ 8 txhuas nyob rau hauv ntau qhov ntau thiab tsawg daim ntawv customization (suav nrog ultra-wide nplooj ntawv)

1/8 " txhuas ntawv yog siv los ua ib daim ntawv, muaj pes tsawg daim nyob rau hauv ib tuj ntawm 1/8 txhuas ntawv? Cia peb suav ua ke;

Cia peb siv ntau tshaj plaws 4 × 8 ko taw 1/8 " txhuas ntawv ua piv txwv, ua ntej peb yuav tsum xam qhov hnyav ntawm txhua daim ntawv txhuas;

Nyhav=Volume x Density=Length x Dav x Thickness x Density
Ntev=8ko taw=2438mm=243.8cm
Dav=4ko taw=1219mm=121.9cm
Thickness=1/8"=3.175mm=0.3175cm
Qhov ceev=2.7g/cm³
Qhov hnyav {{0}}.8cm * 121.9cm * 0.3175cm * 2.7g/cm³=25476.8g=25.4768kg ≈ 25.5kg

1000kg / 25.5kg=39.2 ≈ 39 pieces

Yog li ntawd, muaj 39 daim ntawm 4 × 8 ko taw 1/8 ″ txhuas ntawv ib tuj. Yog tias koj xav tau 1/8 "cov ntawv txhuas, koj tuaj yeem xam kom meej tias muaj pes tsawg tons koj xav tau, uas yooj yim rau koj tso qhov kev txiav txim;



Kev siv ntawm 1/8 "Aluminium Sheet

1/8 " txhuas ntawv tuaj yeem siv dav hauv ntau qhov kev lag luam xws li tsheb, nkoj, roj cia tank, instrumentation, hardware khoom, pwm, thiab lwm yam. Thov xa mus rau cov lus hais txog kev siv 3mm aluminium phaj.



1/8 Nti Aluminium Sheet Rau Tsheb

Aluminium phaj thiab txhuas ntawv ci khoom uas tuaj yeem siv rau hauv kev lag luam tsheb, suav nrog 5182 aluminium alloy phaj, 5083 aluminium alloy phaj, 5754 aluminium alloy phaj, 5052 aluminium alloy phaj ntawm 5000 series txhuas phaj; 6061 aluminium alloy phaj thiab 6063 aluminium alloy phaj yog 6000 series aluminium alloy phaj thiab 6082 aluminium alloy phaj. Cov ntawv thov rau cov khoom lag luam no suav nrog, tab sis tsis txwv rau, cov tsheb thauj khoom hauv qab, cov roj tso tsheb hlau luam, cov neeg caij tsheb lub cev, lub cev qauv, thiab cov radiators. Zoo corrosion kuj, zoo vuam kev ua tau zoo, cov txheej txheem zoo (yooj yim extrusion), yooj yim rau oxidize thiab discolor.



1/8 Nti Aluminium Sheet Rau Nkoj

Cov phaj txhuas rau cov nkoj nuv ntses feem ntau suav nrog 5052, 5083, 6061, thiab 6063, uas raug xaiv raws li qhov loj me thiab siv tau ntawm lub nkoj nuv ntses. Feem ntau, 5052-H32, 5052-H34 los yog 6061-T6 yog siv rau cov hulls me me uas tsis tas yuav tsum tau stretch forms.



Cov nkoj me me siv 5052 lossis 6061 alloy riveted kev tsim kho, thiab cov nkoj nuv ntses loj dua siv 5086 tag nrho-welded tsim. Cov hlau nplaum nrov tshaj plaws rau cov hull yog 5086-H32, uas yog 0.45 txog 12.7 hli tuab, thiab 5086 txhuas ntawv yog kim dua, tab sis kuj muaj zog ntau dua 5052.

Qee lub nkoj nuv ntses yog tsim los ntawm 0.125 "tuab 5052 H32 txhuas ntawv thiab 6061-T6 zoo. 6061 lossis 6063 aluminium alloy extruded profiles yog siv rau cov qauv thiab cov khoom zoo nkauj xws li keels, ru tsev, gunwale thiab dej dav hlau.



1/8 Nti Aluminium Sheet Roj Tank

5xxx series muaj kev tiv thaiv zoo heev thiab kev ua haujlwm vuam, thiab tau siv dav hauv nkoj, tsheb, tsheb thauj mus los, petrochemical thiab lwm yam lag luam. Warwick tuaj yeem muab 5083, 5182, 5454 txhuas daim hlau thiab lwm yam. , haum rau roj tank lub cev.

Cov phaj txhuas feem ntau siv hauv cov tsheb tank feem ntau tsawg dua 12.5 meters ntev thiab tsawg dua 2.2 meters dav. Cov thicknesses feem ntau yog 1/8 nti 3, 4, 5, 6, 7, 8mm. Lub tank ua tiav feem ntau yuav tsum muaj 4-6 cov ntawv txhuas.



1/8 Aluminium Sheet Surface Treatment Txheej txheem

1/8 txhuas ntawv xav tau kev kho deg sib txawv hauv kev siv sib txawv. Peb tuaj yeem tsis tsuas yog muab daim iav kho, kho embossing, xim txheej kho, anodizing, thiab lwm yam, tab sis kuj muab 1/8 checker txhuas ntawv. Customize koj tus kheej cov kev xav tau, peb yuav npaj ntau lawm rau koj sai li sai tau;



1/8 Aluminium Sheet Ntim Thiab Shipping

Peb 1/8 txhuas ntawv yuav tsum tau them nrog xiav zaj duab xis raws li cov kev xav tau ntawm cov neeg muas zaub, los yog muab faib ua cov ntaub ntawv txaj;
Tom qab ntawd siv kraft ntawv los qhwv thiab ntim;
Thaum kawg, siv ntoo pallets los txhawb nqa;







Q: GNEE kev paub txog kev xa tawm mus rau thoob ntiaj teb kev lag luam yog dab tsi?
A: GNEE muaj kev paub dhau los thiab muaj kev sib raug zoo nrog cov neeg siv khoom thoob ntiaj teb.



Q: GNEE lub sijhawm xa khoom yog dab tsi?
A: GNEE tsom rau cov khoom xa tuaj raws sijhawm, nyob ntawm qhov kev txiav txim kom muaj nuj nqis thiab kev hloov kho.



Q: Cov ntawv pov thawj thoob ntiaj teb zoo li cas GNEE muaj?
A: GNEE's aluminium foil khoom yog ISO zoo certified thiab ua raws li cov qauv xws li ASTM thiab EN, kom ntseeg tau cov khoom zoo thiab cov kev pab cuam.




Cim npe nrov: Tuam Tshoj 1/8 Aluminium Sheet Chaw tsim tshuaj paus
