3003-H22 Txhuas Pem Teb Phaj
Kev pabcuam neeg siv khoom yog online. Nkag mus rau kev sib tham kom tau txais cov lus tshaj tawm tshiab.
Khoom muag
Customize
Hoobkas ncaj muag
7 hnub shipping
3003-H22 txhuas pem teb phaj piav qhia
Aluminium 3003 H22 Diamond Tread Phaj yog ib qho khoom siv siv nyob rau hauv ntau yam kev lag luam thiab kev lag luam. No tread phaj yog zoo -}} paub rau nws corrosion tsis kam, muaj peev xwm, thiab lub zog. Nws muaj cov qauv tsa lub pob zeb diamond uas muab cov ntaub so zoo tsis kam rau ntawm cov plag tsev, nce, ntaiv, thiab txoj kev taug.
H22 kev npau taws txhim kho lub zog ntawm no tso cai thaum ua kom nws ua haujlwm, ua rau nws haum rau cov qauv thiab cov ntawv thov dai. Txawm hais tias koj xav txhim kho kev nyab xeeb nyob rau hauv high- cov tsheb khiav mus rau txoj haujlwm fabrication rau txoj haujlwm fabrication, 3003 H22 TEAD Phaj muab kev ua tau zoo.
3003 yog qhov nrov tshaj plaws ntawm txhua txhuas alloys. Nws yog qhov tseem ceeb ua neeg nplua nuj aluminium nrog ntxiv ntawm manganese, uas txhawb lub zog los ntawm kwv yees li 20% saum toj ntawm 1100 qib. Raws li qhov tshwm sim, nws muab cov txiaj ntsig ntawm 1100 nrog ua kom muaj zog ntxiv. Nws muaj kev zam corrosion tsis kam. Nws muaj lub zog ua haujlwm zoo thiab tuaj yeem sib sib zog nqus, spun, welded, lossis brazed. Nws tsis yog cua sov kho tau. Cov ntawv thov suav nrog cov tais diav ua noj, kev ua kom zoo nkauj txiav, mus thoob, sid, tso tsheb hlau luam, thiab tshuaj lom neeg.
| Hlau | Si | Zaum fe | CU | Mn | Mg | Cr | Zn | Ti | Lwm | Al | |
| Ib leeg | Tag nrho | ||||||||||
| 3003 | 0.6 | 0.7 | 0.05~0.20 | 1.0~1.5 | _ | _ | 0.1 | _ | 0.05 | 0.15 | Qho tseg |
Cov Nta Tseem Ceeb:
Alloy: 3003
Templaws: H22 (lim -} tawv thiab ib nrab anealed)
Qauv: Tsa Pob Zeb Diamond Tread
Corrosion Kuj: Zoo heev, tshwj xeeb tshaj yog nyob rau hauv atmospheric thiab cov me ntsis acidic ib puag ncig
Formancion: Zoo
Weldability: zoo heev
Cov Kev Siv Cov Ntaub Ntawv Feem Ntau:
Tsheb loj thiab trailer pem teb
Chaw thau khoom RAMPS
Cuab tam
Walways thiab platform
Chaw Cia thiab Cov Kauj Ruam
Hniav Phab Ntsa Vaj Huam Sib Luag thiab Backsplashes
3003 txhuas pem teb phaj specification
| Khoom | Txhuas Checkered Phaj | |
| Alloy State | Ho, H12, H14, H18, H22, H22, H22, H22, H112, H111, H112, T6 thiab lwm yam. | |
| Qhov tuab | 1.2mm-100 hli | |
| Qhov dav | 600mm-1650mm | |
| Dov Cov Khoom Siv | DC & CC | |
| Teem nqi | 150,1060,1070,1100 thiab lwm yam. 2Txhua: 2a06,2a10,2a12,246,2014,2014,2024,212,224,252524 ect. 3.Series: 3003,3004,3005,3a21,3105 thiab lwm yam. 4Series: 4032,4043,4047 thiab lwm yam. 550,5754,5083, 5086, 5056,52, 5154, 5254, 5454 thiab lwm yam. 6Series: 6061,6062,6083 ect. 7a01,7A04,7005,7050,7075 thiab lwm yam. 8Series: 8011,8079 thiab lwm yam. |
|
| Tus qauv | Loj 5 bar txawv, me ci 5 bar, pob zeb diamond phaj, 2 bar, me me 3, thiab lwm yam. | |
| Nplaim | Zeb ua kom tiav, txhuam hniav, sublimation, daim iav, anodized, embossed, hluav taws xob txheej etc | |
| Lub hom phiaj | GB / T, Astm, en | |
| Ntawv pov thawj | ISO, SGS | |
| Ntim | Ntawv - interleaf txhua nplooj + dej- pov thawj zaj duab xis + ntoo pallets | |
| Lub hauv paus | Phiaj suav | |
| Kev xa mus | 15-20 hnub rau cc txoj kev; 20-25 hnub rau DC txoj kev ntau lawm | |
| Chaw thau khoom chaw nres nkoj | Ib qho chaw nres nkoj ntawm Tuam Tshoj, Tianjin & Qingdao nyob rau hauv qhov muaj feem | |
| Peb Qhov Kom Zoo | Tsis muaj roj stain, tsis muaj khawb, zoo nkauj heev; Ci ntsa iab; Plump thiab sib dhos cov qauv | |
Txhab tuab |
Hauv qab tuab | Txhab tuab |
| 1.2 hli-1.4 hli | 0.4 hli-0.6 hli | |
| 1.4 hli-1.9 hli | 0.8 hli-1.0 hli | |
| 1.9 hli-3.5 hli | 1.0 hli-1.2 hli | |
| 3.5mm-8.0 hli | 1.2mm thiab nce | |
Gnee yog koj cov khoom siv txhim khu kev qha rau high - zoo 3003 phaj txhuas, thiab tsuj taw hauv ntau qhov ntau thiab tsawg thiab cov ntawv. Xijpeem koj cov phiaj xwm yog yog, peb tuaj yeem xa 3003 aluminium alloy cov khoom kom ntsib lawv.Thov kom muaj lus hais hnub noThiab peb yuav zoo siab tham txog koj 3003 aluminium alloy project yuav tsum tau ua.
Peb Qhov Zoo
Gnee tuaj yeem muab 3003/3004 daim hlau txhuas thiab tsuj taw ua raws li ISO tus qauv 6361 thiab B221, B483, B491, thiab B547. Feem ntau siv cov khoom siv siv tau yog H12 thiab H38. Lwm lub tempers tuaj yeem kho tau, thiab tus nqi zoo tshaj plaws thiab kev ua tau zoo yog lav.
1. Gnee tau tsim nyob rau xyoo 2008, uas nyob hauv Suav teb. Cov khoom tseem ceeb muaj xws li: cov phaj aluminium, txhuas raj, txhuas bar, thiab lwm cov ntaub ntawv hlau.
2. Hauv lub xyoo dhau los, peb tau xa cov allots xa tawm mus rau Tebchaws Meskas, Canada, Australia, Singapore, Is Nrias teb, thiab Netherlands.
Lub teb chaws Yelemees, Chile, Moldovina, Argentina, Tebchaws Kauslim, Tebchaws Asmeskas, Tebchaws Africa, Brance, United
Lub Nceeg Vaj thiab Ukraine.
3. Ntau yam khoom lag luam, zoo heev, tsim nyog tus nqi, thiab kev txawj ntse yog tus ntsuj plig ntawm peb lub tuam txhab.
4. Peb muab dab tsi:
1) Kev tswj hwm zoo heev
2) cov nqi sib tw zoo
3) Ib qho - Tsis yuav khoom lag luam Wholesale
4) ODM / OEM Customize Kev Pabcuam
Cim npe nrov: 3003-H22 Txhuam pem hauv paus phaj, Tuam Tshoj 3003-h22 txhuas pua plag phaj phaj
